The CV Watcher image below shows the relationship of the voltages.
The red trace shows the ODD BARS output. The yellow trace shows the EVEN BARS output. The green trace shows the V/BAR input running in a four bar loop. Compare this image with the output traces produced by the Time Split 4 module to get an idea of what’s going on.
Note that when the ODD BARS output is high the EVEN BARS is zero and vice versa.
